Iverntech NEMA 17 Stepper Motor With Integrated T8 Nigeria | Ubuy

Each phase draws current 1.68A, allowing for a holding torque of 40Ncm. Easy to install, durable with alloy steel material. 2-phase 4-wire, 30cm lead wire with XH2.54 connector,no soldering or peeling works. Precisely machined full metal body, heat shrink tubing effect to prevent the wire tangled up. Great replacement for the Z axis of prusa i3 3d printers. Electrical Specification: Motor Type: Bipolar Stepper Step Angle: 1.8 deg. Rated Current/phase: 1.68A Phase Resistance: 1.65Ohm10% Phase Inductance: 3.2mH20% Holding Torque: 40Ncm(56.2oz.in) Rotor Inertia: 54g.cm2 Orientation Torque: 150g.cm Physical Specification: Frame Size: 42 x 42mm Body Length: 40mm Number of Lead wire: 4 Wire Length: 30cm Warning: It should be connected to a constant current or chopper driver as a stepper motor. Connecting the motor directly to a power supply will destroy the motor. Package Included: 1x JOYNANO NEMA 17 Stepper Motor with Integrated 300mm T8 Lead Screw Frame size: 42mm*42mm*40mm. With 1.8° step angle (200 steps/revolution) Precisely machined full metal body, great replacement for the Z axis of prusa i3 3d printers. Key Features High Quality Stepper Motor No shaft coupling needed,integrated with stepper motor and lead screw. T8 Lead Screw Lead screw mainly used in stepper motor, machine tool, and other equipment. Connection Notice As a stepper motor, it should connect to a constant current or chopper driver. Nema 17 Stepper Motor with Integrated 300mm T8 Lead Screw, much stable than shaft coupling connecting
