Multi-Channel Programmable Attenuation Systems

Specification Operating Frequency Range: 1 ~ 3800MHz Input Maximum Power: 20dBm Attenuation Range and Step: Attenuation range from 0~31dB, step size is 1dB Insertion Loss: Less than 2.0dB Attenuation Control: Press OK key, press + after the attenuation digit blinks, - key to control actual addition or subtraction, press OK again to confirm Input Output Impedance: 50Ω Power Supply: MiniUSB 5V Input Output Interface: RP SMA interface Package List: 1 x RF Programmable Attenuator 1 x USB Cable WIDE APPLICABLE: Variable RF attenuator use universal RP SMA interface, suitable for a variety of instruments RELIABLE PCB: Digital RF attenuator module adopts excellent PCB material, with high reliability and miniaturization, good maintenance and interchangeability
